Software module for working with DSG/CVT car transmissions
To use the module, you need to purchase a USB protection dongle. The dongle can be purchased in our store. You can purchase an unlimited number of modules for one dongle.
The module 58 PCM FLASH Temic TCU is designed for the following cars and control units:
- DQ200 (0AM) [VR/WR/CK]
- DQ200MQB/G2 (0CW) [RD/VR/WR/CK]
- DQ250C (02E) [RD/VR/WR/CK]
- DQ250E/F (02E) [VR/WR/CK]
- DQ250MQB (0D9) [RD/VR/WR/CK]
- DQ400 (0DD) [RD/WR/CK]
- DQ500 (0BH/0BT) [RD/WR/CK]
- VL300/V30 (01J/0AN) [VR/WR/CK]
- VL381/DL382 (0AW/0CK) [VR/WR/CK]
- DL501/G2 (0B5) [VR/WR/CK]
- DQ200/MQB/G2/DQ400 Boot (MICRO) [RD/WR/CK]
- DQ200/MQB/G2/DQ400 Boot (EEPROM) [RD/WR]
- DQ250E/F/MQB Boot (MICRO) [RD/WR/CK]
- DQ250E/F/MQB Boot (EEPROM) [RD/WR]
- VL300/V30 BSL (FLASH) [RD/WR/CK]
- VL300/V30 BSL (EEPROM) [RD/WR/CK]
- VL381 Boot (MICRO) [RD/WR/CK]
- VL381 Boot (EEPROM) [RD/WR]
- DL501/G2 Boot (MICRO) [RD/WR/CK]
- DL501/G2 Boot (EEPROM) [RD/WR]
- DL382 Boot (MICRO) [RD/WR/CK]
- DL382 Boot (EEPROM) [RD/WR]
- Honda UDCT Boot (Continental TC1782/MICRO) [RD/WR/CK]
- Honda UDCT Boot (Continental TC1782/EEPROM) [RD/WR]
- EDC DC0/DC4 Gen2 (DKG250 Gen2) Boot (TC1784/MICRO) [RD/WR]
- EDC DC0/DC4 Gen2 (DKG250 Gen2) Boot (TC1784/EEPROM) [RD/WR]
- VGS-FDCT Boot (TC1766/MICRO) [RD/WR]
- VGS-FDCT Boot (EEPROM) [RD/WR]
- VGS2-FDCT Boot (TC1784/MICRO) [RD/WR]
- VGS2-FDCT Boot (TC1784/EEPROM) [RD/WR]
- Haval 7DCT450 Bootloader (EAST80.D1 TC265/MICRO) [RD/WR/CK]
- Haval 7DCT450 Bootloader (EAST80.D1 TC265/EEPROM) [RD/WR]
- Hyundai TAD701/TAD801 D7UF1-2/D7F34-2/D8LF1 Bootloader (TC275/MICRO) [RD/WR/CK]
- Hyundai TAD701/TAD801 D7UF1-2/D7F34-2/D8LF1 Bootloader (TC275/EEPROM) [RD/WR]
VR - virtual reading, RD - reading, WR - writing , CK - verification and checksum correction, NC - checksum not used.
To work through the OBD2 connector, a J2534 adapter is required (Scanmatik 2, OpenPort 2.0, Dialink, Mongoose, etc.). You can buy J2534 adapter in our store.
For quick connection of the control unit, there are special adapters for VAG DSG.
To connect the control unit on the table, you need to purchase additional equipment, any of the following:
Run the program and on the main screen it says "USB dongle serial number"
Launch the program and click “Settings”
Paste the code to activate the module and click “Activate”
After rebooting, the activated module should be displayed, highlighted in bold text.
