Honda Moto Shindengen BitBox

Module for reading and writing Shindengen control units installed on Honda motorcycles.

Shindengen engine control units are based on Renesas V850/RH850 series processors with internal flash memory of 256/384KB.

The module allows identification of software version, virtual reading if a file is available on the server, writing via K-line, checking and counting checksums, and recovery.

If the file is not available on the server, you can send your control unit for reading in our laboratory (the unit will need to be opened).

Which engines and control units are supported by the Bitbox Honda Moto Keihin module:

FID: 337

• Honda Moto Shindengen V850/RH850 K-Line (FID:337)

The module requires the purchase of a USB protection key Bitbox. The key can be purchased in our store. An unlimited number of modules can be purchased for one key.

Module activation is performed within 1 hour on business days (usually 10-15 minutes). Activation may be delayed on weekends and holidays (up to 2 hours).

Module activation requires ONLY the serial number of the key and email.

To work through the OBD2 connector, a J2534 adapter is required (Scanmatik 2, OpenPort 2.0, Dialink, Mongoose, and others). More about J2534 here.

To connect the control unit on the table, additional equipment needs to be purchased, any of the following:

• Combibox
• Powerbox
• Boot/Bench cable for Scanmatik 2 / 2 PRO

Powerbox and Combibox for PCMflash are fully compatible with Bitbox.
