Module for VAG Continental Simos 8.x ECUs (FID: 474, 485, 486)
Module for working with Continental Simos 8.x ECUs used in petrol VAG vehicles.
VAG Continental Simos 8.1X/8.2X/8.3X/8.4X TC1796 BENCH-CAN (FID: 474)
ECUs are based on TC1796 with internal flash memory 2Mb.
Allows reading of FullFlash and writing of calibration area on the BENCH with checksumm correction by CANbus. Also is allows to read and write external EEPROM. No open ECU required. Required SM2/SM2 Pro/SM3 J2534 and special BENCH adapter cable with GPT support.
VAG Continental Simos 8.5X TC1796 BENCH-CAN (FID: 485)
ECUs are based on TC1796 with internal flash memory 2Mb.
Allows reading of FullFlash and writing of calibration area on the BENCH with checksumm correction by CANbus. Also it allows to read and write internal EEPROM. No open ECU required. Required SM2/SM2 Pro/SM3 J2534 and special BENCH adapter cable with GPT support.
VAG Continental Simos 8.6X TC1796 BENCH-CAN (FID: 486)
ECUs are based on TC1796 with internal flash memory 2Mb.
Allows reading of FullFlash+INT.EEPROM and writing of calibration area+INT.EEPROM on the BENCH with checksumm correction by CANbus. Also is allows to read and write external EEPROM. No open ECU required. Required SM2/SM2 Pro/SM3 J2534 and special BENCH adapter cable with GPT support.
Additional ECU types may be supported in the future as development allows.
To use the module, the purchase of a Bitbox USB protection key is required. The key can be purchased in our store. You can buy an unlimited number of modules with one key.
Module activation is done within 1 hour on business days (usually 10-15 minutes). Activation may be delayed during weekends and holidays (up to 2 hours).
To activate the module, ONLY the serial number of the key and email are required.
1. No Refunds or Modifications for Digital Licenses
Activated modules or licenses cannot be returned or refunded.
If an incorrect key or device number is entered by the customer, the purchase is not eligible for return.
Licenses cannot be modified, transferred, or reissued for another device under any circumstances.
2. Irreversible Order Processing
After the order status changes to “Waiting for activation”, the data has already been sent to the developer.
From this point onward, the order cannot be canceled, edited, corrected, or refunded.
3. Responsibility for Software Functionality
Our store is not responsible for the functionality, performance, or declared features of any software module.
We do not guarantee the listed functions because we are not the developer.
4. Accuracy of Product Information
Module and script descriptions are provided directly by the manufacturer.
IOBD.io is not responsible for any inaccuracies, missing details, or differences between the description and actual operation.
In disputed situations regarding functionality or listed features, the customer must contact the manufacturer.
5. Customer Responsibility for Installation
IOBD.io sells professional automotive diagnostic software and equipment.
Installation, setup, configuration, and compatibility checks must be performed by the customer.
We do not provide remote installation, programming, or setup services unless explicitly stated otherwise.
6. Required Technical Knowledge
These products are intended for users with basic technical knowledge in automotive diagnostics.
The customer is fully responsible for understanding the installation process and using the software and hardware correctly.
7. No Liability for Incorrect Usage
IOBD.IO is not responsible for issues caused by:
incorrect installation
unsupported or incompatible hardware
improper configuration
third-party interference
