Software module for working with PSA diesel engine control units.
Module for working through the diagnostic connector via CAN bus with control units installed in diesel vehicles of Peugeot and Citroen.
Which vehicles and control units does the Bitbox PSA Diesel CAN module support:
FIDs: 179, 210, 211, 232
PSA Delphi DCM6.2A (FID: 179)
The control unit is based on the NXP MPC5674 processor with 4.0Mb internal flash memory. Allows reading and writing of calibration area via CAN bus with checksum correction.
PSA Continental SID208 (FID: 232)
The control unit is based on the Infineon Tricore TC1797 processor with 4.0Mb internal flash memory. Allows reading of FullFlash and writing of calibration area through the diagnostic connector with checksum correction. Works only with Scanmatik SM2/SM2 Pro and Openport 2.0 adapters.
PSA Bosch EDC17C10 TC1797 (FID: 210)
The control unit is based on the Infineon Tricore TC1797 processor with 4.0Mb internal flash memory. Allows reading and writing of calibration area via CAN bus with checksum correction.
PSA Bosch EDC17C10 TC1796 (FID: 211)
The control unit is based on the Infineon Tricore TC1796 processor with 4.0Mb external flash memory. Allows reading and writing of calibration area via CAN bus with checksum correction.
The module requires the purchase of a USB dongle for protection Bitbox. The dongle can be purchased from our store. An unlimited number of modules can be activated on one dongle.
Module activation takes place within 1 hour on business days (usually 10-15 minutes). Activation may be delayed on weekends and holidays (up to 2 hours).
To activate the module, ONLY the dongle's serial number and email are required.
To work through the OBD2 connector, a J2534 adapter is required (Scanmatik 2, OpenPort 2.0, Dialink, Mongoose, etc.). More information about J2534 can be found here.
To connect the control unit on the bench, additional equipment needs to be purchased, any of the following:
Powerbox and Combibox for PCMflash are fully compatible with Bitbox.
