Software module for working with ME9/MED9/EDC16 Bootloader engine control units in bootloader (BSM) mode without disassembling the control unit
To use the module, you need to purchase a USB protection key. The key can be purchased in our store. You can purchase an unlimited number of modules with one key.
The module 77 PCM FLASH is designed for the following cars and control units:
- ME9/MED9/EDC7/EDC16/PSG16/TCU (MPC556/MPC562/MPC564) [RD/WR/CK]
- ME9/MED9/EDC7/EDC16/PSG16/TCU MICRO (MPC556/MPC564) [RD/WR/CK]
- ME9/MED9/EDC7/EDC16/PSG16/TCU EXT (MPC556/MPC562/MPC564) [RD/WR/CK]
- ME9/MED9/EDC7/EDC16/PSG16/TCU EEPROM (MPC556/MPC562/MPC564) [RD/WR]
ATTENTION! This module only supports working with control units on the bench.
For operation, the Scanmatik 2 or Scanmatik 2 PRO adapter is required.
To connect the control unit on the bench, additional equipment is required, any of the following:
Run the program and on the main screen it says "USB dongle serial number"
Launch the program and click “Settings”
Paste the code to activate the module and click “Activate”
After rebooting, the activated module should be displayed, highlighted in bold text.
