Module 97 "China AECS/LinControl" for PCMflash
Licence is designed to work with AECS-FC34/50/51 and LinControl LEC4AF/4AP ECUs, which are installed in Chinese-made vehicles with gasoline engines. It supports reading, writing, checksum verification, and correction (if available). The module operates via the OBD diagnostic port or on a bench.
To use the module, you need to purchase a USB protection key. The key can be purchased in our store. You can purchase an unlimited number of modules with one key.
The module supports:
- DAM15KR/EA15MR/SWC14M (LinControl LEC4AF) [RD/WR/NC]
- DAM16KL (LinControl LEC4AP) [RD/WR/NC]
- JAC 2.0T HFC4GA3 (LinControl LEC4AF) [RD/WR/NC]
- JAC 1.5T HFC4GC1 (LinControl LEC4GD) [RD/WR/CK]
- Lixiang 1.5T (LinControl LEC4GD) [RD/WR/CK]
- BAIC 1.5L DAM15KL/R15C1 (AECS FC-34) [RD/WR/CK]
- BAIC 1.6L, 2.0L LQ475QMB/LQ481QFB (AECS FC-50) [RD/WR/CK]
- Changan 1.2L LJ469Q (AECS FC-34) [RD/WR/CK]
- Changan 1.5L DAM15KL (AECS FC-34) [RD/WR/CK]
- Chery 1.5L DAM15KR (AECS FC-34) [RD/WR/CK]
- Dongfeng 1.5L, 1.6L L4A15Q6/LJ4A16QG (AECS FC-34/FC-50) [RD/WR/CK]
- Dongfeng/Fengxing 1.5T 4J15T (AECS FC-34) [RD/WR/CK]
- Dongfeng/Fengxing 1.6L 4A92FR (AECS FC-34) [RD/WR/CK]
- Dongfeng/Fengxing 1.6L CN16 (AECS FC-50) [RD/WR/CK]
- FAW 1.2L LJ469Q (AECS FC-34) [RD/WR/CK]
- FAW 1.5L DAM15KL (AECS FC-50) [RD/WR/CK]
- Foton 1.5L DAM15KL (AECS FC-34) [RD/WR/CK]
- Iran Khodro 1.7L EF7TC (AECS FC-34) [RD/WR/CK]
- JAC 1.6L DAM16KL/HFC4GB3 (AECS FC-34) [RD/WR/CK]
- JAC 1.8L, 2.0L, 2.0T LJ4A18Q6/LJ481Q/HFC4NA3 (AECS FC-34/FC-51) [RD/WR/CK]
- Jinbei/SWM/Brilliance 1.5L SWC15M (AECS FC-34) [RD/WR/CK]
- Jinlu/Jinlong 2.0L LJ481 (AECS FC-34) [RD/WR/CK]
- Joylong 2.4L 4K22D4M (AECS FC-50) [RD/WR/CK]
- King Long/Jinlong 1.8L LJ4A18 (AECS FC-34) [RD/WR/CK]
- LDV/SAIC 1.5L LJ4A15 (AECS FC-34) [RD/WR/CK]
- Longma 1.2L, 1.5L LJ469Q/DAM15KR (AECS FC-34) [RD/WR/CK]
- Nanjun 1.5L LJ4A15 (AECS FC-34) [RD/WR/CK]
- SGMW 1.8L, 2.0L LJ479Q6/LJM20B (AECS FC-34/FC-50) [RD/WR/CK]
- Shandong Kama 1.6L DAM16KR (AECS FC-34) [RD/WR/CK]
- Xiamen Golden Dragon 1.8L, 2.0L LJ4A18/1TZS (AECS FC-34) [RD/WR/CK]
VR - virtual reading, RD - reading, WR - writing , CK - verification and checksum correction, NC - checksum not used.
To work through the OBD2 connector, a J2534 adapter is required (Scanmatik 2, OpenPort 2.0, Dialink, Mongoose, etc.). You can buy J2534 adapter in our store.
To connect the control unit on the bench, additional equipment needs to be purchased, any of the following:
Run the program and on the main screen it says "USB dongle serial number"
Launch the program and click “Settings”
Paste the code to activate the module and click “Activate”
After rebooting, the activated module should be displayed, highlighted in bold text.
