Module for reading and writing of Kefico CPEGD3.20.1, CPEGP3.20.1, CPEGP3.20.2, CPGPSH3.24.1, CPGDSH3.26.2 and CPGPSH3.26.1 ECUs used in petrol Kia and Hyundai vehicles.
Kia/Hyundai Kefico CPEGD3.20.1/CPEGP3.20.1 (FID: 448)
ECU CPEGD3.20.1 is based on MCU Infineon Aurix TC277TP. CPEGP3.20.2 is based on MCU Infineon Aurix TC275TP. Both types are with internal flash memory 4Mb.
Allows reading and writing of calibration area through CAN-bus with checksum correction.
*** - Some hybrid vehicles with CAN FD version of CPEGD3.20.1 are not supported.
Kia/Hyundai Kefico CPEGP3.20.2/CPGPSH3.24.1 (FID: 450)
This ECU type is based on MCU Infineon Aurix TC275TP with internal flash memory 4Mb.
Allows reading and writing of calibration area through CAN-bus with checksum correction.
Kia/Hyundai Kefico CPGPSH3.26.1/CPGDSH3.26.2 (FID: 452)
This ECU type is based on MCU Infineon Aurix TC275TP with internal flash memory 4Mb.
Allows reading and writing of calibration area through CAN-bus with checksum correction.
Kia/Hyundai Kefico CPSCU1.xx.x (FID: 470)
FID supports CPSCU1.11.3, CPSCU1.11.2 and CPSCU1.00.1 ECUs based on MCU Infineon Aurix TC233 with internal flash memory 2Mb.
Kia/Hyundai Kefico CPIMT1.01.1 (FID: 471)
FID supports CPIMT1.01.1 TCUs based on MCU Infineon Aurix TC233 with internal flash memory 2Mb.
Allows FullFlash reading and writing of calibration area through OBD2 or bench by CAN-bus with checksum correction.
To use the module, the purchase of a Bitbox USB protection key is required. The key can be purchased in our store. You can buy an unlimited number of modules with one key.
Module activation is done within 1 hour on business days (usually 10-15 minutes). Activation may be delayed during weekends and holidays (up to 2 hours).
To activate the module, ONLY the serial number of the key and email are required.
To work through the OBD2 connector, a J2534 adapter is required (Scanmatik 2, OpenPort 2.0, Dialink, Mongoose, etc.). More information about J2534 here.
To connect the control unit on the bench, additional equipment from the following list is required:
Powerbox and Combibox for PCMflash are fully compatible with Bitbox.
