Software module for working with GM diesel engine control units.
The module is designed for reading and writing control units installed on diesel vehicles of the GM group (Opel, Chevrolet, Saab, Holden) via the diagnostic connector using the CAN-bus.
Supported vehicles and control units for Bitbox GM Diesel CAN module:
FIDs: 65, 67, 85, 90
GM Bosch EDC16C39 HW1 (FID: 65)
The control unit is based on the Motorola MPC562 processor with external 2.0Mb flash memory.
It allows reading and writing of calibration area via CAN-bus on the bench with checksum correction.
Supported vehicles:
Chevrolet Captiva 2.0 VCDI
Chevrolet Cruze 2.0 VDCI
Chevrolet Epica 2.0 VCDI
Chevrolet Lacetti 2.0 VCDI
Daewoo Winstorm 2.0 VCDI
Opel Antara 2.0 CDTI
Opel Astra (H) 1.9 CDTI
Opel Combo (D) 1.6 CDTI
Opel Signum 1.9 CDTI
Opel Vectra (C) 1.9 CDTI
Opel Zafira (B) 1.9 CDTI
GM Bosch EDC16C39 HW2 (FID: 67)
The control unit is based on the Motorola MPC562 processor with external 2.0Mb flash memory.
It allows reading and writing of calibration area via CAN-bus with checksum correction.
Supported vehicles and control units for Bitbox:
Chevrolet Trailblazer II 2.8TD Duramax
Holden Colorado 2.8TD Duramax
GM ACDelco E87 (FID: 90)
The control unit is based on the Motorola MPC5565 processor with internal 2.0Mb flash memory.
It allows reading and writing of calibration area via CAN-bus with checksum correction.
GM ACDelco E98 (FID: 85)
The control unit is based on the NXP SPC5674 processor with internal 4.0Mb flash memory.
It allows reading and writing of calibration area via CAN-bus with checksum correction.
To use the module, the purchase of a USB security key Bitbox is required. The key can be purchased in our store. One key can activate an unlimited number of modules.
Module activation is performed within 1 hour on business days (usually 10-15 minutes). Activation may be delayed on weekends and holidays (up to 2 hours).
For module activation, ONLY the serial number of the key and email are required.
To work through the OBD2 connector, a J2534 adapter is required (Scanmatik 2, OpenPort 2.0, Dialink, Mongoose, etc.). More information about J2534 here.
To connect the control unit on the bench, additional equipment needs to be purchased, any of the following:
Powerbox and Combibox for PCMflash are fully compatible with Bitbox.
