Software module for working with the engine control unit Gen2 of FCA petrol cars.
Module for working with FCA group (Chrysler/Dodge/Jeep/Fiat) cars through the diagnostic connector with Continental GPEC2 LOCKED, GPEC2A, GPEC3 control units.
These units are installed on petrol cars of the mentioned brands and since 2013 have internal protection (LOCK) against tuning.
Successful writing requires mandatory removal of protection (ECU Unlock) in BSL mode, for which it is necessary to disassemble the unit and connect it "on the table" according to the instructions.
The module allows the following operations:
- Identification and obtaining protection status (LOCKED/UNLOCKED)
- Reading FULLFLASH via OBD2
- Reading EEPROM via OBD2
- Removing ECU Unlock protection in BSL mode
- Writing calibration area via OBD2
- Writing EEPROM via OBD2
- Reading and clearing DTC errors
Which cars and control units does the Bitbox FCA Petrol Gen2 CAN module support:
FIDs: 18, 19, 20, 21
- Continental GPEC2 2013+ MPC5566 3Mb (FID: 20)
- Continental GPEC2 2015+ MPC5566 3Mb (FID: 21)
- Continental GPEC2A MPC5674 4Mb (FID: 19)
- Continental GPEC2A 2018+ MPC5674 4Mb (FID: 131)
- Continental GPEC3 MPC5674 4Mb (FID: 18)
Attention! The protection removal procedure does not work with all J2534 adapters. Currently, Scanmatik SM2, Scanmatik SM2-PRO, CarDAQ Plus, Bosch VCM2, Mongoose (excluding ISO) have been tested and guaranteed to work.
Does not work with Tactrix OpenPort 2.0, Chipsoft J2534, SMS-Soft Dialink.
The module requires the purchase of a USB protection key Bitbox. The key can be purchased in our store. An unlimited number of modules can be purchased for one key.
Module activation is performed within 1 hour on business days (usually 10-15 minutes). Activation may be delayed on weekends and holidays (up to 2 hours).
Only the serial number of the key and email are required to activate the module.
To connect the control unit on the table, additional equipment needs to be purchased, any of the following:
Powerbox and Combibox for PCMflash are fully compatible with Bitbox.
