Toyota Denso Gen4 BENCH-CAN Module – ECU Reading and Writing via CAN for Toyota/Lexus
The Toyota Denso Gen4 BENCH-CAN module is designed for reading and writing ECUs (Engine Control Units) from Toyota and Lexus vehicles via CAN bus on the bench (BENCH mode). It supports ECUs based on Renesas R7F702002 and R7F701216 processors, found in the latest petrol and hybrid models.
Toyota Denso R7F702002 (FID: 444)
Allows to work on the BENCH with exclusive range of the newest Toyota and Lexus petrol vehicles with Denso Gen4 ECUs. This ECUs are based on Renesas R7F702002 MCU with 8Mb internal flash memory.
- Identification
- Real Reading on the BENCH
- Virtual Reading
- Writing on the BENCH with CS check pass
FID covers 7 ECU types that compiled to one common FID with automatic type detection:
- Toyota LC300, Tundra, Lexus LX600 etc with 3.5 Turbo V35A-FTS
- Toyota Tundra/Sequoia Hybrid with 3.5 Turbo V35A-FTS
- 2 types of Lexus LS500 with 3.5 Turbo V35A-FTS
- all known Toyota and Lexus with 2.4 Turbo T24A-FTS
- 2 types of 2.0 M20A-FKS/M20C-FKS and 1.5 M15B-FKS and similar
Toyota Denso R7F701216 Type 1 (FID: 473)
Allows to work on the BENCH with exclusive range of the newest Toyota and Lexus petrol vehicles with Denso Gen4 ECUs. This ECUs are based on Renesas R7F701216 MCU with 4Mb internal flash memory.
- 1.8hyb 2ZRFXE (Corolla, Prius, Voxy, etc)
- 1.5hyb M15AFXS (Yaris Cross, Corolla Cross, Lexus LBX, etc)
- 2.0hyb M20A (Corolla, etc)
- 2.5hyb A25AFXS (Camry, Lexus RX450h+, etc)
- and others...
Toyota Denso R7F701216 Type 2 (FID: 493)
Allows to work on the BENCH with exclusive range of the newest Toyota and Lexus petrol vehicles with Denso Gen4 ECUs. This ECUs are based on Renesas R7F701216 MCU with 4Mb internal flash memory.
- 1.6T G16EGTS GR Yaris 2025+
Toyota Denso R7F701216 Type 3 (FID: 494)
Allows to work on the BENCH with exclusive range of the newest Toyota and Lexus petrol vehicles with Denso Gen4 ECUs. This ECUs are based on Renesas R7F701216 MCU with 4Mb internal flash memory.
- 2.8TD 1GDFTV Toyota LC250
Toyota Denso R7F701216 Type 4 (FID: 507)
Allows to work on the BENCH with exclusive range of the newest Toyota and Lexus petrol vehicles with Denso Gen4 ECUs. This ECUs are based on Renesas R7F701216 MCU with 4Mb internal flash memory.
- 2.7 2TRFE Toyota LC250
Toyota Denso R7F701216 Type 5 (FID: 508)
Allows to work on the BENCH with exclusive range of the newest Toyota and Lexus petrol vehicles with Denso Gen4 ECUs. This ECUs are based on Renesas R7F701216 MCU with 4Mb internal flash memory.
- 3.3TD F33AFTV Toyota LC300
Other ECU types will be added as soon as possible.
To use the module, the purchase of a Bitbox USB protection key is required. The key can be purchased in our store. You can buy an unlimited number of modules with one key.
Module activation is done within 1 hour on business days (usually 10-15 minutes). Activation may be delayed during weekends and holidays (up to 2 hours).
To activate the module, ONLY the serial number of the key and email are required.
To work through the OBD2 connector, a J2534 adapter is required (Scanmatik 2, OpenPort 2.0, Dialink, Mongoose, etc.). More information about J2534 here.
To connect the control unit on the bench, additional equipment from the following list is required:
Powerbox and Combibox for PCMflash are fully compatible with Bitbox.
