Renault / Nissan / Mitsubishi Continental Gen2 BENCH-CAN Module for BitBox
The Renault / Nissan / Mitsubishi Continental Gen2 BENCH-CAN Module is a professional software and hardware solution designed for advanced ECU remapping, chip-tuning, and cloning on a wide range of gasoline and diesel vehicles. This module allows you to work directly with second-generation Continental and Vitesco engine control units using Bench Mode via the CAN bus, eliminating the need to open the unit cover and avoiding any risk of mechanical damage.
FID: 570
To activate the module you need a USB dongle BitBox/BitEdit. When ordering, please indicate the Serial Number of the key.
Supported Protocol Specifications (FID: 570)
The module provides comprehensive identification, reading, and writing functions for the calibration area of Vitesco / Continental EMS314X / EMS316X / SID321 AURIX (4MB / 8MB) systems.
All operations feature automatic checksum correction (CS) during the flash sequence to ensure error-free engine operation after remapping. For select vehicles that are not factory-equipped with a Secure Gateway (SGW) module, diagnostic and flashing operations can also be safely executed directly through the standard OBD-II port.
Supported ECU & Microprocessor Types:
- EMS3140 (Infineon Aurix TC277)
- EMS3141 (Infineon Aurix TC297)
- EMS3142 (Infineon Aurix TC297)
- EMS3160 (Infineon Aurix TC277)
- EMS3161 (Infineon Aurix TC297)
- SID321 (Infineon Aurix TC297)
Important Technical Disclaimers:
- Notice 1 (Anti-Tuning Protection): The latest software updates and factory variations released from 2025 onwards may contain advanced tuning protection patches or locked boot ROM sectors. These newly updated variants are currently under development and are not supported at this moment.
- Notice 2 (Risk of Brick): Writing incompatible firmware, unverified map adjustments, or corrupted files can result in total software failure. Using mismatched files may completely brick the ECU beyond any standard software-based recovery. Always ensure a stable external power supply and double-check binary compatibility before initializing the write protocol.
