Can be used via the OBDII connector or by direct connection via CAN bus with control units of DCM2.5 diesel engines installed on Ashok Leyland, Mahindra, Tata cars, which allows full-fledged work with ECU data for chip tuning.
To use the module, you need to purchase a USB protection key. You can activate an unlimited number of modules with one key. To activate new modules, you need to provide the serial number of your key.
Supported control units:
- Delphi DCM2.5 Ashok Leyland XC2xxx Flash 832 KB (851968 bytes) - read the full contents of the processor\write software and calibration areas.
- Delphi DCM2.5 Mahindra XC2xxx Flash 832 KB (851968 bytes) - read the full contents of the processor\write software and calibration areas.
- Delphi DCM2.5P Tata XC2xxx Flash 1.06 MB (1114112 bytes) - read the full contents of the processor\write software and calibration areas.
Functions:
- Identification
- Reading Errors
- Reset Errors
- Reading Full Flash (enough to restore BSL).
- Recording the control program and calibration area / checking and recalculating the CS calibration area.
- Function record VIN number
Scanmatik adapter recommended
To work, you need a constant connection to the Internet.
Not all software versions may be supported.
Open the program and click “Settings” -> “Number key”
Click “OK” and click ok and your key number will be copied.
After receiving the activation code, click "Enter lecense code" and paste the activation code into the field. After that, restart the program.
An activated module or license cannot be returned.
If you have entered the wrong key or device number, the return is not valid. It is not possible to modify the license for another device.
After status update to "Waiting for activation", the data has already been sent to the developer for activation. The order cannot be canceled or corrected starting from this status update.
Pay attention to all information specified in the description of modules and scripts taken from the manufacturer. We are not responsible if the information is not correct or there are some differences from the reality. In the disputed situation, it is necessary to look for a solution to the issue to the manufacturer.
Our store is not responsible for the functionality of the software module. We cannot guarantee the declared functions since we are not the developer.
