Software module for working with the engine control unit Kefico CPxxxx petrol vehicles Kia/Hyundai.
Module for reading and writing control units Kefico CPGDSh4.2x.x/CPEGD2.20.x and CPGPSh4.14.1/CPEGP2.10.1 installed in petrol vehicles of Korean brands Kia and Hyundai.
Which vehicles and control units are supported by the Bitbox Kia/Hyundai Kefico CPxxxx Petrol CAN module:
FIDs: 251, 253, 303, 304
Kia/Hyundai Kefico CPGDSh4.2x.x/CPEGD2.20.x (FID: 251)
These types of control units operate based on the Infineon Tricore TC1782 processor with internal flash memory of 2.5Mb.
Supported units: CPEGD2.20.1, CPEGD2.20.2, CPEGD2.20.3, CPEGD2.20.4, CPGDSh4.26.1, CPGDSh4.24.4.
Allows reading FullFlash and writing calibration area via CAN bus with checksum correction.
Attention! On some vehicles, the configuration does not allow operation via the diagnostic connector. In this case, it is necessary to work with the unit on the bench, no opening of the unit is required, and the connection is made directly to the ECU connector pins.
Kia/Hyundai Kefico CPGDSh4.2x.x/CPEGD2.20.x BSL (FID: 253)
These types of control units operate based on the Infineon Tricore TC1782 processor with internal flash memory of 2.5Mb.
Allows reading and writing FullFlash in BSL mode. Opening of the unit and connection according to the instructions is required.
Kia/Hyundai Kefico CPGPSh4.14.1/CPEGP2.10.1 (FID: 303)
These types of control units operate based on the Infineon Tricore TC1728 processor with internal flash memory of 1.5Mb.
Allows reading FullFlash and writing calibration area via CAN bus with checksum correction.
Attention! On some vehicles, the configuration does not allow operation via the diagnostic connector. In this case, it is necessary to work with the unit on the bench, no opening of the unit is required, and the connection is made directly to the ECU connector pins.
Kia/Hyundai Kefico CPGPSh4.14.1/CPEGP2.10.1 BSL (FID: 304)
These types of control units operate based on the Infineon Tricore TC1728 processor with internal flash memory of 1.5Mb.
Allows reading and writing FullFlash in BSL mode. Opening of the unit and connection according to the instructions is required.
To use the module, you need to purchase a Bitbox USB dongle . You can purchase the dongle in our store. One dongle can be used to activate an unlimited number of modules.
Module activation is done within 1 hour on business days (usually 10-15 minutes). Activation may be delayed during weekends and holidays (up to 2 hours).
To activate the module, ONLY the serial number of the dongle and email are required.
To work through the OBD2 connector, a J2534 adapter is required (Scanmatik 2, OpenPort 2.0, Dialink, Mongoose, etc.). Learn more about J2534 here .
To connect the control unit on the bench, the purchase of additional equipment from the following list is required:
Powerbox and Combibox for PCMflash are fully compatible with Bitbox.
