Denso SH7058/SH7059 CAN BitBox

Universal software module for working with Denso SH7058 / SH7059 CAN engine control units.

Module for working through the diagnostic connector or on the table with Denso control units based on Renesas SH7058 and SH7059 processors.

Which cars and control units does the Bitbox Denso SH7058/SH7059 CAN module support:

Denso SH7058/SH7059 (FID: 153)

Allows identification, reading and writing of FullFlash, checksum verification and counting.

Supports brands: Nissan, Mitsubishi, Subaru, Mazda, Opel, Hyundai Trucks

In testing phase: Hino, Suzuki, Volvo, Kubota

Attention!

Some cars do not have the CAN bus connected to the diagnostic connector. Some have gateways that interfere with the bootloader operation. In these cases, use the table connection.

Some cars have a +24V network voltage, before starting work, check if your J2534 supports this voltage.

The module requires the purchase of a USB protection key Bitbox. The key can be purchased in our store. An unlimited number of modules can be purchased for one key.

Module activation is performed within 1 hour on business days (usually 10-15 minutes). Activation may be delayed on weekends and holidays (up to 2 hours).

To activate the module, ONLY the serial number of the key and email are required.

To work through the OBD2 connector, a J2534 adapter is required (Scanmatik 2, OpenPort 2.0, Dialink, Mongoose, etc.). More about J2534 here.

To connect the control unit on the table, additional equipment is required, any of the following:

• Combibox
• Powerbox
• Boot/Bench cable for Scanmatik 2 / 2 PRO

Powerbox and Combibox for PCMflash are fully compatible with Bitbox.
