Scania EMS BENCH-CAN Module (FIDs: 404, 405, 498)
A professional module designed for working with Scania EMS control units on the bench via CAN bus with automatic baud rate detection (250/500 Kbps). Enables software reading, writing, and identification without connecting to the vehicle.
Key Features:
- Software version identification in the ECU
- FullFlash reading of ECU firmware
- Writing firmware with automatic checksum correction
- Bench mode operation – no need to connect to the truck
- Supports EMS control units installed in Scania heavy-duty trucks
Scania Continental EMS S8/EMD1 (FID: 404)
This FID is for working with Continental EMS S8/EMD1 ECUs based on MCU NXP MPC5566 with internal flash memory 3 Mb.
Allows Full Flash reading and writing with checksum correction by CANbus on the BENCH.
Scania Motorola EMS S7 (FID: 405)
This FID is for working with Motorola EMS S7 ECUs based on MCU NXP MPC563 with internal flash memory 512 Kb.
Allows Full Flash reading and calibration writing with checksum correction by CANbus on the BENCH.
Scania Motorola EMS S6 (FID: 498)
This FID is for working with Motorola EMS S6 ECUs based on MCU NXP MPC565 with internal flash memory 448 Kb.
Allows Full Flash reading and software writing with checksum correction by CANbus on the BENCH.
To use the module, you need to purchase a Bitbox USB protection key. The key can be purchased in our store. An unlimited number of modules can be purchased for one key.
Module activation is done within 1 hour on business days (usually 10-15 minutes). Activation may be delayed on weekends and holidays (up to 2 hours).
To activate the module, ONLY the serial number of the key and email are required.
To work through the OBD2 connector, a J2534 adapter is required (Scanmatik 2, OpenPort 2.0, Dialink, Mongoose, and others). More about J2534 here.
To connect the control unit on the table, you need to purchase additional equipment, any of the following:
Powerbox and Combibox for PCMflash are fully compatible with Bitbox.
An activated module or license cannot be returned.
If you have entered the wrong key or device number, the return is not valid. It is not possible to modify the license for another device.
After status update to "Waiting for activation", the data has already been sent to the developer for activation. The order cannot be canceled or corrected starting from this status update.
Pay attention to all information specified in the description of modules and scripts taken from the manufacturer. We are not responsible if the information is not correct or there are some differences from the reality. In the disputed situation, it is necessary to look for a solution to the issue to the manufacturer.
Our store is not responsible for the functionality of the software module. We cannot guarantee the declared functions since we are not the developer.
