China Bosch Ecu Petrol BENCH/OBDII.
Module for reading in BSL mode (with disassembly on the table) and writing without disassembly on the table or in the car.
Supported ECU types:
- Bosch M7.9.7 K-Line
Module based on C167 processor with external 512kb Flash, supports BSL reading, writing on the table without disassembly or in the car, checksum correction.
- Bosch ME7.9.7 K-Line
Module based on C167 processor with external 1Mb Flash, supports BSL reading, writing on the table without disassembly or in the car, checksum correction.
- Bosch M7 /Bosch M7.8 /Bosch M7.8.0 /Bosch M7.8.8 /Bosch M7.9.7.1K-Line
Modules based on ST10F275 processors with internal 832kb Flash memory, supports BSL reading, writing with protection disabled, on the table without disassembly or in the car, checksum correction.
- Bosch M7.8.8 CAN
Modules based on ST10F27rts BSL reading, writing with protection disabled, on the table without disassembly or in the car, checksum correction.
Not all software versions may be supported.
To use the module, you need to purchase a USB protection key. You can activate an unlimited number of modules with one key. To activate new modules, you need to provide the serial number of your key.
Open the program and click “Settings” -> “Number key”
Click “OK” and click ok and your key number will be copied.
After receiving the activation code, click "Enter lecense code" and paste the activation code into the field. After that, restart the program.
