Software module for working with DCM6.2AP and DCM7.1AP family ECUs installed on Chinese vehicles.
To use the module, you need to purchase a USB protection key. The key can be purchased in our store. You can purchase an unlimited number of modules with one key.
Which vehicles and control units is the 90 PCM FLASH module intended for:
- BAIC 2.0L TD (DCM6.2AP) [RD/WR/CK]
- BAIC 2.0L TD EEPROM (DCM6.2AP) [RD/WR]
- Changan 2.0L TD (DCM7.1AP) [RD/WR/CK]
- Dongfeng 2.3L TD (DCM7.1AP) [RD/WR/CK]
- Dongfeng/Yuchai 2.4L TD (DCM7.1AP) [RD/WR/CK]
- Great Wall/Haval 2.0L TD (DCM6.2AP) [RD/WR/CK]
- Great Wall/Haval 2.0L TD (DCM7.1AP) [RD/WR/CK]
- Great Wall/Haval 2.0L TD EEPROM (DCM7.1AP) [RD/WR]
- JAC 2.0L TD (DCM6.2AP) [RD/WR/CK]
- JAC 2.0L TD EEPROM (DCM6.2AP) [RD/WR]
- Jiangling/Isuzu 2.8L TD (DCM7.1AP) [RD/WR/CK]
- Qingling/Isuzu 3.0L TD (DCM6.2AP) [RD/WR/CK]
- Qingling/Isuzu 3.0L TD (DCM7.1AP) [RD/WR/CK]
- SsangYong: 2.2L XDI (DCM6.2AP/6D/S2) [RD/WR/CK]
- SsangYong: 2.2L XDI (DCM6.2AP/6D/S2) EEPROM [Test] [RD/WR]
- Trucks (DCM6.24) [Test] [RD/WR/CK]
- Foton/Vanche/Yuchai 2.4L TD (DCM7.24) [RD/WR/CK]
- Foton/Vanche/Yuchai 2.4L TD EEPROM (DCM7.24) [RD/WR]
- Foton/Yuchai 4.2L, 4.3L TD (DCM7.24) [RD/WR/CK]
- Foton/Yuchai 4.2L, 4.3L TD EEPROM (DCM7.24) [Test] [RD/WR]
- JCB 4.4L TD (DCM2.7AP) [RD/WR/CK]
- JCB 4.4L TD EEPROM (DCM2.7AP) [Test] [RD/WR]
- JCB 4.4L, 4.8L TD (DCM7.24) [RD/WR/CK]
- JCB 4.4L, 4.8L TD EEPROM (DCM7.24) [RD/WR]
Reading and writing is supported through the vehicle's diagnostic connector, as well as checksum verification and correction.
To work through the OBD2 connector, a J2534 adapter is required (Scanmatik 2, OpenPort 2.0, Dialink, Mongoose, etc.). More information here.
To connect the control unit on the bench, additional equipment is required, any of the following:
Run the program and on the main screen it says "USB dongle serial number"
Launch the program and click “Settings”
Paste the code to activate the module and click “Activate”
After rebooting, the activated module should be displayed, highlighted in bold text.
