Toyota Denso Diesel 7 Module – Calibration of Denso Gen4 ECUs for Toyota Diesel Vehicles
Toyota Denso Diesel 7 module is designed for calibration and modification of ECU firmware in Denso Gen4 diesel Toyota vehicles. It’s a professional tool for tuning and diagnostic specialists, offering access to essential engine management and injection control maps.
To activate the module you need a USB key BitBox/BitEdit. When ordering, please indicate the Serial Number of the key.
Supported Engines:
- 2.8TD 1GD-FTV
- 3.3TD F33A-FTV
Compatible Parameters:
- File sizes: 4Mb and 8Mb
- Software versions: 8A222-xxxxx
Available Calibration Maps:
- Air Calculation
- Airflow correction
- Desired air calculation in additional mode
- Boost Pressure
- Base boost pressure
- Boost with active EGR
- Minimum boost pressure
- Boost Pressure Correction
- Correction by intake air temperature
- Correction by atmospheric pressure
- Correction by coolant temperature
- Boost Pressure Limitation
- EGR
- Basic EGR position
- Lower and upper torque thresholds for EGR activation
- Fuel Pressure
- Start-up fuel pressure
- Coolant temperature-based correction
- Regeneration mode pressure
- Rail pressure
- Maximum fuel pressure
- Injection Timing and Volume
- Initial injection phase
- Injection volume limits
- Max injection volume correction
- 0th, 1st, 2nd, and 3rd pilot injection volumes
- Limiters
- Engine speed limiter
- Minimum RPM limiter
- Vehicle speed limiter (Test mode)
- Nozzle Performance
- Pilot and main injection performance
- Post Injection
- Post-injection phase settings
- Sensors
- Coolant temperature sensor
- Exhaust temperature scaling
- Intake air and manifold temperature scaling
- SCR temperature scaling
- Torque
- Requested torque
- Torque loss (fuel pump, coolant temp, pressure)
- VNT / VGT Control
- Base and max VNT position
- EGR-dependent VGT parameters
- Proportional control coefficients
- VNT Correction
- Additional VNT base position correction
- DTC Support
- DTC table editing and diagnostics support
