GAZ/VAZ M12/M74.5/M75(KLINE) M86(CAN) PETROL ECU BENCH/OBDII.
The module allows you to work with control units of petrol engines ITELMA, MIKAS via OBDII connector or Bench mode, based on Infineon XC27xx processors installed on GAZ, UAZ, VAZ cars.
Supported ECUs:
- MIKAS 12(GAZ) via KLINE
- ITELMA M74.5(VAZ) via KLINE
- ITELMA M75(VAZ) via KLINE
- ITELMA M86(VAZ) via CAN
Supported processors:
- XC2060 - firmware size of FLASH memory 832 KB (851,968 bytes)
- XC2765 - firmware size of FLASH memory 832 KB (851,968 bytes)
- XC2768 - firmware size of FLASH memory 1088 KB (1,114,112 bytes)
Supported functions:
- ECU identification
- Recorder reading - reads ECU recorder data via OBDII or direct connection on the bench
- Reading/deleting ECU errors
- ECU reset
- ECU initialization
- Reading/writing ECU FLASH
- Reading/writing EEPROM
- Recorder editor - allows editing recorder data
- Recovery mode
Not all software versions may be supported.
To use the module, the purchase of a USB protection key. You can activate an unlimited number of modules with one key. To activate new modules, you need to provide the serial number of your key.
-
