Works with direct connection via CAN/K-Line bus (depending on the selected ECU type) with Delphi control units installed on cars of various Chinese manufacturers, which allows for full-fledged chip tuning work with ECU data.
To use the module, you need to purchase a USB protection key. You can activate an unlimited number of modules with one key. To activate new modules, you need to provide the serial number of your key.
Reading the full contents of the microcontroller/writing the control program and calibration area recalculation of the calibration area CS:
- Delphi MT20U MC912DT128 128Kb K-Line;
- Delphi MT20U2 MC9S12KG256 256Kb K-Line;
- Delphi MT22U MS9S12XET256 256Kb K-Line;
- Delphi MT22.1 MS9S12XEP768 768Kb K-Line;
- Delphi MT22.1.1 MS9S12XET256 256Kb K-Line;
- Delphi MT22.5 MS9S12XEP768 256Kb K-Line;
- Delphi MT80 TC1762 1.4 Mb K-Line;
- Delphi MT92 TC17XX 2 Mb CAN;
- Delphi MT92.1 TC17XX 2.5 Mb CAN.
Reading the full contents of the microcontroller/writing the control program and calibration area without recalculating the CS:
- Delphi MT62.1_JAC SPS5634 1.5 Mb CAN
Functions:
- Identification;
- Read/Clear DTC;
- Reading Full FLASH;
- Flash recording (application and calibration area);
- Recalculation of checksums (Not all software versions may be supported).
Scanmatik adapter recommended.
To work, you need a constant connection to the Internet.
Open the program and click “Settings” -> “Number key”
Click “OK” and click ok and your key number will be copied.
After receiving the activation code, click "Enter lecense code" and paste the activation code into the field. After that, restart the program.
An activated module or license cannot be returned.
If you have entered the wrong key or device number, the return is not valid. It is not possible to modify the license for another device.
After status update to "Waiting for activation", the data has already been sent to the developer for activation. The order cannot be canceled or corrected starting from this status update.
Pay attention to all information specified in the description of modules and scripts taken from the manufacturer. We are not responsible if the information is not correct or there are some differences from the reality. In the disputed situation, it is necessary to look for a solution to the issue to the manufacturer.
Our store is not responsible for the functionality of the software module. We cannot guarantee the declared functions since we are not the developer.
