Ford Bosch MG1/MD1 Gen2 Module for BitBox
FIDs: 513, 514, 515, 516, 517, 518, 519, 520, 524, 526
The BitBox Ford Bosch MG1/MD1 Gen2 module is designed for professional chip tuning workshops and service centers working with Ford vehicles. It supports both BENCH (on-table) and OBD modes, including reading and writing of protected Bosch MG1/MD1 Gen2 ECUs (2020+).
To activate the module you need a USB key BitBox/BitEdit. When ordering, please indicate the Serial Number of the key.
Main Functions of the Module
- Software version identification (SW ID)
- Reading of SOFT + CAL areas
- Writing of SOFT + CAL areas
- CS verification and correction
- Reading and clearing of DTC errors via OBD
BENCH Mode (on-table)
BENCH mode provides fast and stable performance. Available only with the Scanmatik 3 adapter.
Supported ECUs:
- Ford Bosch MD1CP061 TC298 8MB BENCH [SM3 ONLY] (FID: 524)
- Ford Bosch MD1CS025 TC387 10MB BENCH [SM3 ONLY] (FID: 516)
- Ford Bosch MD1CS027 TC387 10MB BENCH [SM3 ONLY] (FID: 532)
- Ford Bosch MG1CS036 TC399 16MB BENCH [SM3 ONLY] (FID: 513)
- Ford Bosch MG1CS040 TC399 16MB BENCH [SM3 ONLY] (FID: 514)
- Ford Bosch MG1CS060 TC387 10MB BENCH [SM3 ONLY] (FID: 515)
BENCH mode is essential for ECU recovery after interrupted flashing or when working with protected units.
OBD Mode (via diagnostic connector)
In OBD mode, the module works with any high-quality J2534 adapter.
⚠️ Important: this mode is very sensitive to voltage drops. To ensure safe flashing, a high-quality power supply or charger is required. If the process is interrupted, use BENCH mode with Scanmatik 3 for ECU recovery.
Supported ECUs:
- Ford Bosch MD1CP061 TC298 8MB OBD (FID: 526)
- Ford Bosch MD1CS025 TC387 10MB OBD (FID: 520)
- Ford Bosch MD1CS027 TC387 10MB OBD (FID: 533)
- Ford Bosch MG1CS036 TC399 16MB OBD (FID: 517)
- Ford Bosch MG1CS040 TC399 16MB OBD (FID: 518)
- Ford Bosch MG1CS060 TC387 10MB OBD (FID: 519)
An activated module or license cannot be returned.
If you have entered the wrong key or device number, the return is not valid. It is not possible to modify the license for another device.
After status update to "Waiting for activation", the data has already been sent to the developer for activation. The order cannot be canceled or corrected starting from this status update.
Pay attention to all information specified in the description of modules and scripts taken from the manufacturer. We are not responsible if the information is not correct or there are some differences from the reality. In the disputed situation, it is necessary to look for a solution to the issue to the manufacturer.
Our store is not responsible for the functionality of the software module. We cannot guarantee the declared functions since we are not the developer.
