VAG Continental Simos 12/16/18/PCR2 Module [SM2/SM3 ONLY] for BitBox
FID: 401, 402, 403, 406, 410, 411
This module is designed for working with VAG Continental ECU including Simos 12.X, Simos 16.11, Simos 18.X, Simos 18.10, and PCR2.1. It operates within the BitBox software environment and is compatible only with Scanmatik 2 / 2 Pro and Scanmatik 3 adapters. The module supports FullFlash read and calibration write with automatic checksum correction. Depending on the ECU model, the connection is made on the bench via GPT using either BENCH-CAN or BSL mode.
Note: To work with the module need a BitBox/BitEdit protection key, one key can activate an unlimited number of modules.
Supported VAG Continental ECUs and Operation Modes
Simos 12.X (FID: 401, 406)
- Models: Simos 12.1, Simos 12.2
- Processor: Infineon TC1797, 4Mb internal flash
- Mode: BENCH-CAN (no ECU opening required)
- Features: FullFlash read and calibration write with checksum correction
- Requirements: Scanmatik 2/2 Pro/3 + GPT-compatible bench adapter
Simos 16.11 (FID: 410)
- Processor: Infineon TC1791, 4Mb internal flash
- Mode: BSL (requires ECU opening and soldering)
- Features: FullFlash read and calibration write with checksum correction
- Requirements: Scanmatik 2/2 Pro + GPT bench adapter
Simos 18.X (FID: 402)
- Models: Simos 18.1, 18.2, 18.3, 18.6, 18.7
- (Simos 18.3 – experimental support)
- Processor: Infineon TC1791, 4Mb internal flash
- Mode: BSL (requires ECU opening and soldering)
- Features: FullFlash read and calibration write
- Requirements: Scanmatik 2/2 Pro + GPT adapter
Simos 18.10 (FID: 403)
- Processor: Infineon TC1791, 4Mb internal flash
- Mode: BSL
- Features: FullFlash read and calibration write with checksum correction
- Requirements: Scanmatik 2/2 Pro/3 + soldering + GPT bench adapter
PCR2.1 (FID: 411)
- Processor: Infineon TC1796, 2Mb internal flash
- Mode: BENCH-CAN (no ECU opening required)
- Features: FullFlash read and calibration write with checksum correction
- Requirements: Scanmatik 2/2 Pro/3 + GPT-compatible bench adapter
An activated module or license cannot be returned.
If you have entered the wrong key or device number, the return is not valid. It is not possible to modify the license for another device.
After status update to "Waiting for activation", the data has already been sent to the developer for activation. The order cannot be canceled or corrected starting from this status update.
Pay attention to all information specified in the description of modules and scripts taken from the manufacturer. We are not responsible if the information is not correct or there are some differences from the reality. In the disputed situation, it is necessary to look for a solution to the issue to the manufacturer.
Our store is not responsible for the functionality of the software module. We cannot guarantee the declared functions since we are not the developer.
