PSA FULL Module set

This is a full set of ABRITES functionalities for PSA vehicles including the PN009, PN017, PN018, PN019 licenses.

The PN009 Engine Control Unit Advanced Diagnostic is a powerful license for Peugeot and Citroën vehicles with the following capabilities:

• Read/Update the Configuration Data (EDC15, EDC17(BOOT MODE), SID201, SID801, SID801A, SID802, SID803, SID803A, SID804, SID806;)
• Read/Update the flash
• Make IMMO OFF (EDC15)
• Modify/Reset service intervals (EDC15, SID201, SID801, SID801A, SID802, SID803, SID803A, SID804, SID806;)
• Read/Update the PIN codes of Engine Control Units (EDC15, SID201, SID801, SID801A, SID802, SID803, SID803A, SID804, SID806;)

Read and calibrate the mileage in the dashboard of EDC16, EDC17(BOOT MODE), SID201, SID801, SID801A, SID802, SID803, SID803A, SID804, SID806;

PN017 - BSI, Instrument Cluster Data Manager is a leader in field of Instrument cluster and BSI odometer data calibration and covers the whole range of Peugeot/ Citroën (PSA) group vehicles. It is very useful in the following situations:

• Read and calibrate the mileage stored in the instrument cluster and BSI module by OBDII
• Disable the synchronisation between the dashboard and BSI module when the calibrating the mileage in the BSI is not possible

Supported Vehicles:

?ll CAN and UDS protocol models which include almost all models produced after 2004. Support for Delphi UDS BSI 2016+ included.
