Orange 5

Original programmer Orange 5 is a professional memory and microcontroller programmer.

Orange 5 is designed for working with automotive electronics, EEPROM chips, TMS, MCUs used in immobilizers, control units, radios, and other automotive electronic devices. A unique feature of programmers in this series is the built-in macro language for protocol description, HPL.

Technical specifications of the Orange 5 programmer:

• Connection and power via USB2.0 / 3.0 interface
• Universal panel with zero insertion force ZIF16 for EEPROM
• Contact control in the panel
• 2 expansion connectors: Orange4, and Omega MTRK
• Overcurrent protection
• Overvoltage protection
• 2 power modes with automatic detection: standard (USB) and enhanced (USB + external power supply)
• 3 voltage sources with current limiting and level control: supply voltage (adjustable 2.0...5.0V), programming voltage (adjustable 2.0...21.0V), additional unregulated 10V for microcontrollers
• High-speed bidirectional pin drivers with output level adjustment (2.0...5.0V)
• Frequency adjustable clock signal generator (up to 24 MHz) and output level (2.0...5.0V)
• Functional emulation of USB CDC class devices
• Built-in 32-bit virtual machine
• Support for I2C, SPI, MicroWire, JTAG, UART, BDM, ISO7816, K-LINE (via adapter), CAN (via adapter) interfaces
• Enclosure design

Software:

• Maximum buffer size - 32Mb
• Ability to add custom HPL modules
• Editing of 8-bit and 16-bit HEX values, as well as ASCII
• Reading and writing files in bin, hex, S19 formats
• Visual comparison mode with highlighted values
• Full chip or specified area writing
• Support for multiple configuration files
• Automatic saving of archival copies (backup)
• Extended set of buffer operations
• Works under Windows XP, Windows 7 (32/64 bit)
• Additional features are supported by the O5TOOL program

Supported chips:

• I2C, SPI, MicroWire, 1-Wire, Serial FLASH, NAND FLASH, microcontrollers from Atmel, Fujitsu, Freescale, MediaTek, MicroChip, Motorola, NEC, NSC, Philips, Renesas, Samsung, ST, Texas Instruments
• A complete list of supported chips can be found here

Complete set:

• Orange-5 programmer
• USB cable
