The ON013 - PIN and Key Manager is a great single solution for reading and extracting the PIN codes, key and remote control programming for Opel/Vauxhall/Buick/Cadillac/Chevrolet/GMC vehicles.
Main functionalities of this license are:
- Read Security Code
- Key Learning
- Read/Update ConfData
Supported brands and models:
- Buick - Enclave, Encore, GL8 II, LaCrosse, Lucerne, Regal, Verano
- Cadillac - ATS, DTS, Escalade 2007, Escalade 2015, SRX 2007, SRX 2010, XT5, XTS
- Chevrolet - Avalanche, Camaro, Captiva, Colorado, Corvette 2014, Cruze, Equinox 2007, Equinox 2010, Express, Impala 2006, Impala 2014, Malibu, Orlando, Silverado 2007, Silverado 2014, Sonic, Spark, Suburban 2007, Suburban 2014, Tahoe 2007, Tahoe 2014, Tracker, Trax, Volt.
- GMC - Acadia, Canyon, Savana, Sierra 2007, Sierra 2014, Terrain, Yukon 2007, Yukon 2015.
- Opel/Vauxhall - Adam, Agila A, Agila B, Antara, Astra F, Astra G, Astra H, Astra J, Astra K, Calibra, Corsa B, Corsa C, Corsa D, Corsa E, Insignia A, Insignia B, Karl / Viva, Meriva A, Meriva B, Mokka, Monterey, Movano, Movano 2007, Omega B, Sintra, Tigra A, Tigra B, Vectra B, Vectra C/Signum, Vivaro, Vivaro 2007, Zafira A, Zafira B, Zafira C
Supported Models for Reading Security Code:
- Buick – Encore, LaCrosse, Regal, Verano
- Cadillac – ATS, SRX, XTS
- Chevrolet – Camaro, Corvette, Cruze, Equinox, Impala, Malibu, Orlando, Silverado, Sonic, Spark, Suburban, Tahoe, Volt
- GMC – Canyon, Sierra, Terrain, Yukon
- Opel/Vauxhall – Adam, Agila, Astra F, Astra G, Astra H, Astra J, Astra K, Calibra, Corsa B, Corsa C, Corsa D, Insignia A, Insignia B, Meriva A, Meriva B, Mokka, Omega B, Tigra A, Tigra B, Vectra B, Vectra C/Signum, Zafira A, Zafira B, Zafira C
Read/Update ConfData:
- Instrument Panel Cluster (Astra G)
- Instrument Panel Cluster (Corsa C, Meriva, Tigra B)
- Engine Magneti Marelli MJD 6JO - Z13DT (Corsa C, Agila, Tigra B)
- Engine Magneti Marelli MJD 6O2 - Z13DTH (Astra H, Corsa D)
- Engine Magneti Marelli MJD 6O3 - Z13DTJ (Corsa D)
- Engine Siemens VDO SIMTEC 70 - X18XE1, X20XEV
- Engine Siemens VDO SIMTEC 71 - Z18XE, Z22XE
- Engine Siemens VDO SIMTEC 71.1 - Z18XE, Z18XEL
- Engine Siemens VDO SIMTEC 71.5/71.6 - Z18XE
- Engine Siemens VDO SIMTEC 75 - Z16XER, Z18XEP
- Engine Siemens VDO SIMTEC 81 - Z22YH
- Engine Denso 64F7058 (93C86) - Z30DT (Vectra C/Signum)
- Engine Denso 64F7059 (93C86) - A17DTR, A17DTL, A17DTJ (Astra J, Meriva B)
- BCM Delphi 70F3238 (93C86)
- BCM Delphi 70F3379 (93C86)
- BCM Delphi 70F3633
- BCM Bosch 70F3385 (24C16)
- BCM Bosch 70F3469 (24C16)
- BCM Bosch 70F3558 (24C32)
- BCM Continental 70F3469 (95160/25160)
- BCM Continental 70F3558 (95320/25320)
N.B. Please note that you will require an AVDI interface and active AMS in order to purchase this special function.
Important:
This function is available only on certain BMW engines and is NOT applicable to other vehicle brands.
The information below applies only to stock engines with factory ECU software and a standard exhaust system.
What This Parameter Actually Represents
This is NOT a direct measurement of fuel octane and is NOT a direct octane reading calculated by the ECU.
The value is an adaptation factor ranging from 0 to 1, where:
- 0 = no correction
- 1 = maximum correction
According to BMW’s internal definition:
Faktor adaptierte Kraftstoffqualität (0 = ROZ98 / 1.0 = ROZ91)
- 0 corresponds to 98 ROZ
- 1.0 corresponds to 91 ROZ
ROZ is the German equivalent of RON (Research Octane Number).
The device converts this multiplier into a more intuitive octane value for user convenience.
⚠️ The device does not measure anything itself.
It only displays the data provided by the engine control unit (ECU).
How the ECU Evaluates Fuel Quality
Each ECU has different calibration sensitivity:
- Sensitivity to the adaptation factor
- Sensitivity of the knock control system
Fuel quality is evaluated subjectively by the ECU, primarily based on:
- Knock ignition timing corrections
- Overall engine noise levels
BMW G-Series & LCI F-Series (B-Engines)
B38 / N63 / S63 / N74
These engines are highly sensitive to octane adaptation.
- During warm-up and cruising, the displayed octane may frequently drop to 95 or lower.
- This does NOT automatically indicate poor fuel quality.
- Under load, the value should increase.
⚠️ If the value continues to decrease under load, this may indicate a problem.
B46 / B48 / B58
These engines have low sensitivity.
- During cruising, octane will typically display maximum values even with mediocre fuel.
- Under load, the value will decrease if fuel quality is truly poor.
S58
Octane correction is virtually inactive.
- It will typically always show 98.
- If it drops below 98, fuel quality is genuinely very poor.
BMW F-Series (Pre-LCI) with N/S Engines
Most pre-LCI F-series ECUs do not calculate octane adaptation.
Do not expect this parameter to function.
S55
- Octane parameter not used by the system
- Display not supported
- However, display of the last 5 refueling quality events is supported
S63
- Octane parameter not used
- Display not supported
- Refueling quality display not supported
BMW E-Series
Octane parameter not available. Display not supported.
Important Notes About Tuned Vehicles
With modified hardware or custom tuning, behavior may vary significantly. Always consult your tuner regarding expected operation.
Key principles:
- If octane drops under load, it means fuel quality is worse than expected under those conditions.
- This does NOT automatically mean the fuel itself is bad.
Examples:
- If a tuner increases ignition timing and boost pressure, even good fuel may cause knock corrections, and the ECU may interpret it as poor fuel.
- Thin-walled or poorly mounted exhaust systems may create parasitic noise, which the ECU may interpret as engine knock, causing negative correction.
- Conversely, if knock sensitivity is reduced or octane correction is disabled in tuning, readings may appear ideal while actual engine safety is compromised.
