The Full Mercedes-Benz cars package includes the MN030, MN032 and MN033 licenses. Below you can see what each one of them covers as functionalities.
MN033 is dedicated to resolving a problem with the "ELV Component Fault" which is preventing the vehicle from being started and driven.
This is a common fault in the Electronic Steering Lock (ESL/ELV) modules. The MN033 enables you to clear the critical error which blocks the vehicle's electronic steering lock.
This function is performed with a direct connection to the ELV diagnostic line. It can be executed direct in the vehicle or on bench!
Supported vehicles:
- ALL FBS4 vehicles with ESL/ELV modules!
The usage of the ZN051 ABRITES Distribution Box is recommended for this license.
MN032 is a world leader in terms of Mercedes-Benz vehicles module replacement, key and remote programming, both for new and used control units.
FBS4 functionalities
- Reset of FBS4 Engine control units to virgin state
- Read the personalization data from a FBS4 ECU and saving it to a file for future use
- Program personalization data from a previously saved file to a FBS4 ECU
- FBS4 ECU Activation
Currently supported ECUs (produced until MY2020):
- CR40 (EDC17C43)
- CR41 (EDC17C66)
- CR42 (EDC17CP46)
- CR43 (EDC17CP60)
- CR6 (EDC17CP10)
- CR60 (EDC17CP46)
- CR61 (EDC17CP57)
- MED40 (MED17.7.1 and MED17.7.2)
- MED177 (MED17.7.3, MED17.7.5, MED17.7.8)
- CRD3
- CRD3H
- CRD3S2
VGS-NAG2 FBS4 Transmission control units are also supported for renewal.
The newly added modules include:
• ECU CRR1 (SID307) and CRR1+(SID310) – Done completely by OBD.
• ECU MRD1, MRG1 (manufactured up to 2021) – Bench connection using ZN051 Distribution box and EP003 are required.
• ECU CRR2 (MD1CS006) – Bench connection using ZN051 Distribution box and EP003 are required.
• ECU MED41 (MED17.7.7) – Bench connection using ZN051 Distribution box and EP003 are required.
• Transmission Control Unit VGSNAG3 (9-Gear) - Bench connection using ZN051 Distribution box and EP003 are required.
• Transmission Control Unit VGS2-FDCT (Dual Clutch Transmission)- Bench connection using ZN051 Distribution box and EP003 are required.
• Direct Shift Module (DSM) – ABPROG (ZN030) is required to connect to the module’s microcontroller and read data directly from it to extract the data and use it with the Abrites software.
FBS3 functionalities
Module replacement:
- Service password reading
- Read/Save/Update FBS Data
- Transfer FBS Data to a replacement unit
- Make each DAS/FBS module virgin, personalise and activate it
- Read/Save/Update Coding (the only way to avoid online SCN coding)
- Transfer Coding to a replacement unit
Key programming:
- Easily extract the EZS/EIS key password
- Program all types of DAS2 keys
- Program Infra Red keys to DAS3 (FBS3)
- Enable and disable key positions
Supported Models:
- W202/W208/W210
- W203/W209/W211/W219
- W169/W245
- W220/W215/R230
- W204/W207/W212/W218
- W221/W216/W251/W164/X164
- W176/W246/W242/W117
- W166/X166
Supported Modules are all DAS related modules
- ECUs
- TCUs (7G-Tronic)
- ISM
- DSM
- ESL/EZS
- EIS/ELV
Other features:
- Program the Abrites Emulators for Mercedes vehicles (EM001, EM004, EM005, EM008, EM009, EM012, EM014)
- Reset the mileage of any supported EZS/EIS.
Additional and required tools:
- ZN051 Abrites Distribution Box
- ZN002 Abrites PROTAG programmer
- ZN030 Abrites ABPROG
- Abrites IR keys, keys with replica shells and Abrites IR PCBs: TA13, TA14, TA15, TA21, TA22, TA52
The ZN076 is highly reccomended for faster reading information from the EZS/EIS of Mercedes-Benz vehicles with IR locks.
N.B. Please note that you will require an AVDI interface with an active AMS in order to use this special function.
The MN030 is the latest development dedicated to odometer calibration and module replacement by OBDII for dashboards of FBS4 vehicles equipped with IC213 or IC222 dashboard
Main functionalities:
- Blocks synchronisation between the Instrument Cluster and the EZS (for models with IC213)
- Allows successful mileage calibration
- Allows modules replacement (dashboard) - Make virgin and Adapt
Different retrofit options like update from analogue to digital dials
Supported models:
- W213
- W205
- W222
- W217
- W238
- W253
- W257
- W463
- W447 (with IC213)
- related models
Models with dashboard IC222 (require emulator*)
*EM008/EM009/EM014 is used for w205 and w222 (both before facelift)
An AVDI interface with a valid AMS subscription are required for the purchase and use of this package.
-
