Hyundai/Kia Siemens SIM2K ECU BENCH/OBDII.
Module supports work with Siemens ECUs with INFINION TRICORE and MOTOROLA MPC5xx processors installed on Hyundai/Kia vehicles.
Through the OBDII connector via CAN bus (on a vehicle with a working immobiliser) with engine control units:
- SIM2K-240 - firmware size of FLASH memory 2.00 MB (2,097,152 bytes)
- SIM2K-241 - firmware size of FLASH memory 2.00 MB (2,097,152 bytes)
- SIM2K-242 - firmware size of FLASH memory 2.00 MB (2,097,152 bytes)
- SIM2K-245 - firmware size of FLASH memory 2.00 MB (2,097,152 bytes)
Through the OBDII connector via CAN bus (on a vehicle or when directly connected on a table) with engine control units:
- SIM2K-141 - firmware size of FLASH memory 2.00 MB (2,097,152 bytes)
- SIM2K-142 - firmware size of FLASH memory 2.00 MB (2,097,152 bytes)
- SIM2K-143 - firmware size of FLASH memory 2.00 MB (2,097,152 bytes)
- SIM2K-341 - firmware size of FLASH memory 2.00 MB (2,097,152 bytes)
Through the OBDII connector via K-LINE (on a vehicle or when directly connected on a table) with engine control units:
- SIM2K-D160 - firmware size of FLASH memory 2.00 MB (2,097,152 bytes)
Supported functions:
- ECU identification
- Reading/deleting fault codes
- Reading Full Flash/writing calibration and ECU program area
- Automatic verification of ECU firmware checksum in the calibration area
Not all software versions may be supported.
To use the module, you need to purchase a USB protection key. You can activate an unlimited number of modules with one key. To activate new modules, you need to provide the serial number of your key.
-
There are no reviews for this product.
-
No questions yet
Open the program and click “Settings” -> “Number key”
Click “OK” and click ok and your key number will be copied.
After receiving the activation file, click "Update license in key" and open the module license file.
An activated module or license cannot be returned.
If you have entered the wrong key or device number, the return is not valid. It is not possible to modify the license for another device.
Pay attention to all information specified in the description of modules and scripts taken from the manufacturer. We are not responsible if the information is not correct or there are some differences from the reality. In the disputed situation, it is necessary to look for a solution to the issue to the manufacturer.
Our store is not responsible for the functionality of the software module. We cannot guarantee the declared functions since we are not the developer.
