Dacia/Lada/Nissan/Renault ECU MCU C167 BENCH/OBDII.
Allows reading and writing of FULL Flash 29F200/29F400 image.
Also includes a function for reading/writing the emulated Flash EEPROM.
The "MAKE VIRGIN" function allows you to make the ECU "New", suitable for installation in a car and further adaptation for operation.
Reading/Writing works even with immobiliser locked, allowing immobiliser repair without ECU disassembly.
A firmware read in this way completely matches the firmware read by a programmer on the "panel".
Work is done by directly connecting to the ECU, without ECU disassembly.
List of supported ECUs:
- Sirius 32 KLINE
- Sirius 32 CAN
- Sirius 34 KLINE
- Sirius 34 CAN
- Siemens EMS 3132 KLINE
- Siemens EMS 3132 CAN
- Siemens EMS 3134 KLINE
- Siemens EMS 3134 CAN
- Continental EMS 3132
- Continental EMS 3134
- Siemens SIM 32 CAN
Approximate list of supported cars:
- Renault Logan
- Renault Symbol
- Renault Scenic
- Renault Laguna
- Renault Megane
- Lada Largus
- Dacia Logan
- Nissan Almera
To use the module, you need to purchase a USB protection key. One key can activate an unlimited number of modules. To activate new modules, you need to provide the serial number of your key.
Open the program and click “Settings” -> “Number key”
Click “OK” and click ok and your key number will be copied.
After receiving the activation file, click "Update license in key" and open the module license file.
An activated module or license cannot be returned.
If you have entered the wrong key or device number, the return is not valid. It is not possible to modify the license for another device.
After status update to "Waiting for activation", the data has already been sent to the developer for activation. The order cannot be canceled or corrected starting from this status update.
Pay attention to all information specified in the description of modules and scripts taken from the manufacturer. We are not responsible if the information is not correct or there are some differences from the reality. In the disputed situation, it is necessary to look for a solution to the issue to the manufacturer.
Our store is not responsible for the functionality of the software module. We cannot guarantee the declared functions since we are not the developer.
