Magneti Marelli ECU Reading and Writing Module via CAN Bus (BENCH-CAN)
This module is designed for reading and writing Magneti Marelli ECUs via CAN bus on the bench (BENCH mode) without opening the ECU. Suitable for diesel and gasoline vehicles of various brands that use Magneti Marelli control units with MPC5XXX and TC277 microcontrollers.
The module operates by connecting directly to the ECU via CAN bus on the bench. ECU removal is required, but no disassembly is needed. A bench adapter with automatic power management is required for proper operation.
Magneti Marelli MPC5XXX BENCH-CAN (FID:460)
Features:
- Software version identification
- FullFlash reading
- FullFlash writing
- Checksum correction during writing
- ECU recovery
- EEPROM reading and writing
Supported ECU types:
- MJD 8F2 — MPC5565 + 95640
- MJD 8F3 — MPC5565 + 95640
- 8GMC — MPC5565 + 95128
- 8GMF HW503 — MPC5565 + 95128
- 8GMK — SPC564A80 (MPC5644) + 95128
- 8GMW — MPC5565 + 95128
- 8GSW — MPC5565 + 95128
- 8GSF — MPC5565 + 95640
- 9GF — SPC564A70 (MPC5642) + 95640
- 10JA — MPC5777 + 95128
Magneti Marelli TC277 BENCH-CAN (FID:503)
Features:
- Software version identification
- FullFlash reading
- Writing of software and calibration (SOFT + CAL)
- Checksum correction during writing
- ECU recovery
- Reading and writing of internal and external EEPROM
Supported ECU types:
- 11GC — TC277 + internal EEPROM + 95256
- 11GDB — TC277 + internal EEPROM
- 11GF — TC277 + internal EEPROM + 95640
- 11MP — TC277 + internal EEPROM + 95640
To use the module, the purchase of a Bitbox USB protection key is required. The key can be purchased in our store. You can buy an unlimited number of modules with one key.
Module activation is done within 1 hour on business days (usually 10-15 minutes). Activation may be delayed during weekends and holidays (up to 2 hours).
To activate the module, ONLY the serial number of the key and email are required.
To work through the OBD2 connector, a J2534 adapter is required (Scanmatik 2, OpenPort 2.0, Dialink, Mongoose, etc.). More information about J2534 here.
To connect the control unit on the bench, additional equipment from the following list is required:
Powerbox and Combibox for PCMflash are fully compatible with Bitbox.
An activated module or license cannot be returned.
If you have entered the wrong key or device number, the return is not valid. It is not possible to modify the license for another device.
After status update to "Waiting for activation", the data has already been sent to the developer for activation. The order cannot be canceled or corrected starting from this status update.
Pay attention to all information specified in the description of modules and scripts taken from the manufacturer. We are not responsible if the information is not correct or there are some differences from the reality. In the disputed situation, it is necessary to look for a solution to the issue to the manufacturer.
Our store is not responsible for the functionality of the software module. We cannot guarantee the declared functions since we are not the developer.
