ChipTuningPRO EXT module for ME17 [176] module expansion

Module ChipTuningPro allows you to expand the functionality of ME17 modules.

Additional features:

• Shuffling of calibrations for Bosch ME17.9.7 firmware of VAZ and UAZ cars. This function requires the presence of the module ME17.9.7 VAZ/UAZ
• Patch to disable the ability to read Bosch ME17.9.7, Bosch ME17.9.71 (VAZ, UAZ), Bosch ME17.9.11/12 and ME17.9.21 (Kia, Hyundai) firmware using diagnostic methods. This function requires the presence of any module for working with ME17 ECU family
• Function to save the original CVN of the edited firmware. Supported for Bosch ME17.9.11/12 and ME17.9.21 (Kia, Hyundai). This function requires the presence of any module for working with the listed ECUs

Module features:

• All serial firmware of VAZ and UAZ cars equipped with Bosch M(E)17.9.7 ECUs are supported
• It is not allowed to write only the calibration area using the "diagnostic" writing method (without disassembling the ECU), as this will result in the loss of ECU functionality (ECU recovery will only be possible by rewriting Full-Flash via BSL mode)
• By default, firmware of Bosch ME17 controllers is saved in SMS-Soft Container File format. To load such firmware, only CombiLoader should be used
• Saving in the usual BIN format is possible
• Shuffling of calibrations for multi-mode ME17.9.7 software is not possible

To use the module, the purchase of a ChipTuningPro USB protection key is required. The key can be purchased in our store. An unlimited number of modules can be purchased for one key.

Updates of descriptions for new software versions within the module are free.

Module activation is performed within 1 hour on business days (usually 10-15 minutes). Activation may be delayed on weekends and holidays (up to 2 hours).

To activate the module, you need to send a request for module activation, full name, and email.
