$119.47
* +4% Order Processing Fee applies. No extra payment service fees.
Haval H6/H9/F7 DASH BENCH/OBDII.
The module supports working with microcontrollers Renesas RH850 R7F701404, RH850 R7F701442, NEC 70F3529, NEC 70F3532 in Continental VDO instrument panels installed in Haval H6/H9/F7, GreatWall Poer cars.
The work is carried out through the OBDII diagnostic connector or on the bench (connection is described in the manual) in Bench mode.
Supported functions:
- Instrument panel identification
- Reading/deleting fault codes
- Reading/writing KM
- Reading data area (virtual EEPROM)
- Writing data area (virtual EEPROM)
- Reading CFlash
- Reading/changing VIN
- ECU reset (as if turning on)
- Resetting the inter-service interval
- Reading/writing configuration
Not all software versions may be supported.
To use the module, you need to purchase a USB protection key. You can activate an unlimited number of modules with one key. To activate new modules, you need to provide the serial number of your key.
Open the program and click “Settings” -> “Number key”
Click “OK” and click ok and your key number will be copied.
After receiving the activation code, click "Enter lecense code" and paste the activation code into the field. After that, restart the program.
1. No Refunds or Modifications for Digital Licenses
Activated modules or licenses cannot be returned or refunded.
If an incorrect key or device number is entered by the customer, the purchase is not eligible for return.
Licenses cannot be modified, transferred, or reissued for another device under any circumstances.
2. Irreversible Order Processing
After the order status changes to “Waiting for activation”, the data has already been sent to the developer.
From this point onward, the order cannot be canceled, edited, corrected, or refunded.
3. Responsibility for Software Functionality
Our store is not responsible for the functionality, performance, or declared features of any software module.
We do not guarantee the listed functions because we are not the developer.
4. Accuracy of Product Information
Module and script descriptions are provided directly by the manufacturer.
IOBD.io is not responsible for any inaccuracies, missing details, or differences between the description and actual operation.
In disputed situations regarding functionality or listed features, the customer must contact the manufacturer.
5. Customer Responsibility for Installation
IOBD.io sells professional automotive diagnostic software and equipment.
Installation, setup, configuration, and compatibility checks must be performed by the customer.
We do not provide remote installation, programming, or setup services unless explicitly stated otherwise.
6. Required Technical Knowledge
These products are intended for users with basic technical knowledge in automotive diagnostics.
The customer is fully responsible for understanding the installation process and using the software and hardware correctly.
7. No Liability for Incorrect Usage
IOBD.IO is not responsible for issues caused by:
incorrect installation
unsupported or incompatible hardware
improper configuration
third-party interference
