Software module for engine control unit Denso Gen3 CAN vehicles.
Module for reading and writing through the CAN bus of Toyota Denso and Fujitsu Ten Gen3 control units, installed in Toyota/Lexus petrol and diesel vehicles.
Supported vehicles and control units by Bitbox module for Toyota Denso Gen3 CAN:
Toyota Denso Gen3 R7F701202 (FID: 149)
Supported Denso control units based on the Renesas R7F701202 processor with 4Mb internal flash memory.
The module allows:
- Software version identification
- Reading
- Writing with checksum correction
Supported models:Lexus ES250 ES300h (ZA10, ZH10) |
Supported engines:2.0 M20AFKS |
Toyota Denso R7F701216 Type 2 BENCH-CAN (FID: 235, 236)
Allows:
- Software version identification
- Virtual reading
- Writing with checksum correction on the bench
Supported vehicles: Toyota Yaris GR 1.6T G16E-GTS and Toyota Land Cruiser 300/Lexus LX500d 3.3TD F33A-FTV.
Toyota Denso Gen3 R7F701216 Type 3 BENCH-CAN (FID: 345)
Allows:
- Software version identification
- Reading on the bench
- Writing with checksum correction on the bench
Supported vehicles: Toyota Yaris and Yaris Cross with engines 1.5hyb M15AFXS and 1.5 M15AFKS. Also used for real reading of LC300/LX500d 3.3TD F33AFTV.
Attention! Writing a modified file with incorrect error mask disable will result in the block bricking without the possibility of recovery.
Attention! Diesel vehicles with Denso Gen3 control units currently have limited support. Work is available with Toyota HiLUX 2.4TD/2.8TD with Gen3 units. Toyota HiACE is not supported. More models will be added if possible.
To use the module, the purchase of a Bitbox USB protection key is required. The key can be purchased in our store. You can buy an unlimited number of modules with one key.
Module activation is done within 1 hour on business days (usually 10-15 minutes). Activation may be delayed during weekends and holidays (up to 2 hours).
To activate the module, ONLY the serial number of the key and email are required.
To work through the OBD2 connector, a J2534 adapter is required (Scanmatik 2, OpenPort 2.0, Dialink, Mongoose, etc.). More information about J2534 here.
To connect the control unit on the bench, additional equipment from the following list is required:
Powerbox and Combibox for PCMflash are fully compatible with Bitbox.
