Dacia/Lada/Nissan/Renault Bosch ABS/ESP BENCH/OBDII.
The module works through the OBDII connector via the CAN bus with ABS/ESP BOSCH 9.0-9.1 blocks based on TMS470, TMS570 microcontrollers with EEPROM chips 95128/95320/95640 installed on Renault, Dacia, Nissan, VAZ vehicles.
The module performs safe and complete repair, restoration, and replacement of data blocks. These ECUs have been installed since 2014 and are still in use today.
The EEPROM reading/writing procedure takes from 7 to 15 seconds, depending on the type of memory chip in the ECU and the adapter used.
Supported functions:
- Identification of ABS/ESP ECU
- Reading/deleting fault codes
- Reading/writing EEPROM
- Reading/writing FULL FLASH (only program and calibration area)
- Reading/changing vehicle VIN code
- ECU reset
- Fully automatic backup creation
Approximate list of vehicles equipped with this ECU:
- Dacia Duster
- Dacia Logan
- Dacia Sandero
- Lada Vesta
- Lada X-Ray
- Nissan Terrano
- Renault Duster
- Renault Logan
- Renault Sandero
- Renault ClioIV
- Renault Captur
- Renault Kaptur
The module has been tested on the following ECUs:
- TMS470+95320 2014
- TMS470+95320 2015
- TMS570+95128 2016
- TMS570+95128 2017
- TMS570+95128 2018
- TMS570+95128 2019
- TMS570+95128 2020
- TMS570+95320 2017
- TMS570+95640 2016
Not all software versions may be supported.
To use the module, you need to purchase a USB protection key. You can activate an unlimited number of modules with one key. To activate new modules, you need to provide the serial number of your key.
-
There are no reviews for this product.
-
No questions yet
Open the program and click “Settings” -> “Number key”
Click “OK” and click ok and your key number will be copied.
After receiving the activation file, click "Update license in key" and open the module license file.
An activated module or license cannot be returned.
If you have entered the wrong key or device number, the return is not valid. It is not possible to modify the license for another device.
Pay attention to all information specified in the description of modules and scripts taken from the manufacturer. We are not responsible if the information is not correct or there are some differences from the reality. In the disputed situation, it is necessary to look for a solution to the issue to the manufacturer.
Our store is not responsible for the functionality of the software module. We cannot guarantee the declared functions since we are not the developer.
